Cream Soap Bar P90 Pickup Cover


Notify me when this product is available:

WD "Soap Bar" P-90 Pickup Cover

Commonly referred to as a soap-bar P-90 pickup cover, this cover has been used for decades to house P-90 pickups in guitars like the Gibson® Les Paul® and SG®. Mounting screws travel through the center of the pickup/cover and mount directly to the body of the instrument with no need for pickguard or mounting rings. Mounting screws not included.

O.D. dimensions
Width = 3 23/64 in. (85.4mm)
Length = 1 23/64 in. (34.6mm)
Height = 5/8 in. (16.06mm)
I.D. Dimensions
Width = 3 13/64 in. (81.4mm)
Length = 1 13/64 in. (30.57mm)
Depth = 9/16 in. (14.15mm)
Pole Piece spacing = 1 31/32 in. (50mm)
Mounting screw hole location = 25/32 in. (20mm) apart
25/64 in. (10mm) from center

Type: Guitar Parts
